Hesotec Electrify eSat r10 SMART - 3.6KW - 11KW

Hesotec Electrify eSat r10 SMART - 3.6KW - 11KW

The eSat r10 Smart charging column combines intelligent technology with premium German engineering, making it the ideal choice for both private and commercial EV charging. With a sleek, modern design and durable construction, it offers a future-proof solution that looks as good as it performs.

Delivering a 3.6KW - 11KW charging power, the eSat Smart provides fast, reliable charging for single vehicles or multiple fleets. Sessions can be started and managed via RFID card, or through the eCC smartphone app, which enables real-time monitoring, remote control, and even billing integration. Built-in WiFi ensures seamless connectivity, allowing you to manage and optimise your charging stations with ease.

The eSat Smart series is particularly well-suited to commercial fleets, hotels, workplaces, and public spaces, while also offering advanced functionality for private households that want the very best in EV charging technology.

Specification:

• Maximum charging power: 3.6 KW -11KW
• Maximum charging current: 16 A
• MID-compliant energy meter
• DC residual current detection
• Freely positionable for indoor and outdoor use
• Authorisation via RFID or smartphone using eCC App (electrify Charge Control) or Plug & Start
• LAN, WiFi and digital inputs
• Master / Slave via electrify Mesh
• OCPP integration
• Modbus TCP
• Free backend via eLMS (electrify Load Management System): load management, evaluations and more
• Charging socket: Type 2
• Climate control system with axial fan and heater
• Protection class: IP54
• Easy installation

Scope of Delivery:

• eSat r10 Smart
• 1x RFID card
• Ground Mounting Frame
• Mounting hardware
• Digital input adapter
• Device ID
• Quick installation guide
