Hesotec Electrify eBox WR30-R BASE - 7.4KW - 22KW

Hesotec Electrify eBox WR30-R BASE  - 7.4KW - 22KW

The wr30 Base wallboxes are ideal for private use.  We offer them with 3.6KW - 11KW or 7.4KW - 22KW maximum charging power. They are easy to handle and ready to use anytime.

High-quality stainless steel makes our wallbox extremely weather-resistant. It has a timeless, yet unpretentious shape. Also, its design is customisable! You can charge your electric car at 3.6KW - 11KW or 7.4KW - 22KW maximum charging power via an integrated charging cable. Just plug in the socket or start the charging process via RFID or eCC app. Of course, you can manage and operate the charging process on your smartphone.

Specification:

• Max. charging power: 7.4KW - 22 KW
• Max. charging current: 32 A
• DC fault current detection
• Orientation: horizontal, right-curved design
• Authorisation via RFID, smartphone via eCC App (electrify Charge Control) or Plug & Start
• Wi-Fi and digital inputs
• Master / Slave via electrify Mesh
• Modbus TCP
• Either 4 m, 5m, 7m or 8m charging cable (Type 2)

• Climate system with axial fan and heater
• Protection class: IP54
• Easy installation

Scope of delivery:

• eBox wr30-R
• 1x RFID card
• Wall mounting adapter for surface installation
• Mounting hardware
• Digital input adapter
• Device ID
• Quick installation guide
